Radial inductor DR18*20 inductor 1.2mm wire Low-resistance Leaded Power Inductor Coils , High-current Power Inductors

DR radial inductor
The DR inductor is a small electric component which occupies a small area on PCB. The four models of our DR inductor mainly differ in appearance. The two pins of the PK model are on the same side, while the VC model put the pins on separated sides. Different models may have different overall sizes, pin lengths, pin diameters, or pin intervals. Our production process is very precise so that the difference in pin length is less than 2mm, and the difference in pin intervals is less than 0.3mm.

Feature

1. Factory price driectly
2. Comparaticely large rated current
3. inductance ranging from 0.33uH to10000uH
4. ROHS approval

Operating temperature: -55 to 105°C
Power: 200, 250, 300 and 500W
Voltage: 100V/230, 50Hz
Inductance value is 60μH±10% at 1KHz 0.25V

DCR is 35mΩMAX a t 20℃

Rated current is 4A
PF value: greater than 98%
Tested at 100kHz, 0.1Vrms inductance of 10%uH
DC current at which the inductance drops 10% (type) from itsvalue without current
Electrical characteristics at 25°C
Insulation: class B (130°C), class F (155°C), class H(180°C), class N (200°C) and class R (220°C)
Certifications: UL, CQC and CE
Excellent utilization of electricity, good for environment protection
Customized specifications are accepted

Applications:

Frequency power
UPS
EMI/RFI filters
Switching power output and smoothing circuits
Used as choke coil for high frequency SMPs
Countermeasure against spike ripples
DC/DC converters
Battery power equipment
Power supply of all types of household appliances
Switching power supplies
